THERMTEC PRO COFFEE COVERS

PORTABLE TEMPERATURE INSTRUMENTS WITH OR WITHOUT RECORDER, CONNECTION CABLE WITH COMPUTER, DATA TRANSFER TO COMPUTER, PROTECTIVE TRANSFER BALLET WITH 2 K-Type HEAT DATA, BATTERIES AND MANUAL.

The thermometers Coffeelovers Thermtech Accurate & Thermtec Per are low-power instruments using for temperature measurement a thermocouple, mainly of the type ” K “. It applies a cyclic measurement technology, so the sampling rate is 2 times per second. Thanks to the principle of high-precision circuit and high-precision reference source inside the instrument, combined with accurate factory calibration, the resolution of the instrument reaches 0.01 ℃ and the factory accuracy reaches ±(0.3%|t||+0.40) ℃ .

1. The Thermtec Pro adds a recording function based on all the above functions of the Thermtec Accurate . 2.

2. M can record all data when measuring the temperature.

3. The files created from the recording can be viewed directly on this machine or on any device such as P . C ή laptop that supports reading the U disk.

4. It also uses data space partitioning technology, so it can export files in a variety of different formats e.g. ( excel ).

5. Importantly, files stored on the instrument can be restored and transferred to other devices at any time. This backup measure effectively reduces the risk of accidental data loss by their users.

– e.g. reading a measurement and transferring the files in a format excel .

E Extract the information, draw curves that suit your needs and share them with your partners. Gain insight and make decisions that will make your job easier.

FEATURES

– High-speed, low-power 32-bit MCU

– Double channel

– K, T and J type thermocouples are supported

– Resolution up to 0.01 ℃

– Factory accuracy ±(0.3%|t|+0.40)℃

– Accuracy up to ±0.1 ℃ after point calibration

– Measuring range K type: -200~1370 ℃ // T type: -200~400 ℃ // J type: -200~1200 ℃

– The temperature difference value between two channels is displayed

– Display temperature graph

– Over-limit alarm function

– Maximum, minimum and average data display

– Sampling rate 2 times/second

– Support for multiple power solutions

– Large LCD screen, high quality backlight

【 SPECIFICATION 】

Model	YET-620	YET-620L
Channel	2
record function	No	Yes
Support probe type	K, T, J type thermocouple
Unit	℃ , ℉
Measuring range	K type: -200~1370 ℃ T type: -200~400 ℃ J type: -200~1200 ℃
Resolution	0.01 ℃ (-200.00~999.99 ℃ ) 0.1 ℃ (1000.0~1370.0 ℃ )
Native accuracy	±(0.3%|t|+0.40) ℃
Measuring rate	2 times/second
User calibration method	multi-point calibration
storage capacity	No	20000 sets of measured values
Record sampling interval	No	1~86399 seconds adjustable
Output file format	No	txt, csv, xls, dlg
Compatible system	No	Windows XP/Vista/7/8/10
Display	Dot matrix LCD screen with backlight
operating temperature	-10~50 ℃ (non-condensing)
storage temperature	-20~60 ℃ (without battery)
power supply	3 pcs of 1.5V AAA alkaline batteries 3 pcs of 1.2V AAA rechargeable batteries 5V USB (not recommended)
battery life	About 190 hours (conditions: the instrument continues to work, the backlight is off, the battery capacity is 1200mAh, and the ambient temperature is 25 ℃ )
protection class	IP52
Dimensions

Weight	2 kg
